FITTING & ACCESSORIES
>EARTH TAG
EARTH TAG
1. MateriaI
Brass/Brass with nickel plated / Stainless Steel
※ The length of the thread can be changed on required.
| ETType/Size | Thread Size | H | M | T | L | W | |
|---|---|---|---|---|---|---|---|
| PF | NPT | Metric | |||||
| ET-16 | 3/8" | M16 | 23 | 17 | 1.5 | 49 | 6 |
| ET-20 | 1/2" | M20 | 30 | 21.5 | 1.5 | 56 | 7 |
| ET-25 | 3/4" | M25 | 35 | 27 | 1.5 | 62 | 8 |
| ET-32 | 1" | M32 | 44 | 33.5 | 1.5 | 74 | 12 |
| ET-40 | 1-1/4" | M40 | 52 | 42 | 1.5 | 81 | 14 |
| ET-50 | 1-1/2" | M50 | 63 | 50.5 | 1.5 | 101 | 14 |
| ET-63 | 2" | M63 | 78 | 64 | 1.5 | 118 | 14 |
| ET-75 | 2-1/2" | M75 | 92 | 76 | 1.5 | 131 | 14 |
| ET-90 | 3" | M90 | 109 | 91 | 1.5 | 162 | 15 |
| ET-100 | 3-1/2" | M100 | 120 | 101 | 1.5 | 177 | 15 |
| ET-115 | 4" | M115 | 134 | 116 | 1.5 | 190 | 15 |
